[Majestouch 2 is now available finally!]

Better typing feel? The superior quality we have been seeking is now available! In pursuit of the real taste of The Cherry MX switch, we have focused on improving "typing experience" thoroughly by renewing from the first process. Enjoy yourself with this real keyboard.

Cherry MX Brown Switch :
Known as tactile, there is a very soft click as you reach the contact point.
With the light pressure spring, it makes typing action easy, fast and stress free.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.

Cherry MX Black Switch :
Known as linear - you don't feel clicking when pressing down.
Just a smooth action.
It has characteristics that the stress transfers with proportional linearity.
You need a certain pressure to press down however it doesn't have to reach the contact point to be recognized by using repelling force.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.

Cherry MX Blue Switch :
Known as tactile feel.
You can enjoy clicking with an audible click and a tactile feel.
The key switch has gold plated contacts which make the contact even with a small force once it is typed.
It has a characteristics that makes mechanical clicking sounds.
A long key stroke of 4mm and the contact point at 2mm between the key strokes.

Cherry MX Red Switch :
Cherry MX red has got the same feature of Cherry MX black switch.
They are linear type which makes no clicking sounds. Spring pressure is only up to 45g so that it provides you a smooth light typing feel!

[PC board got all renewed! It delivers you a better duration, quality and typing feel!]

Double layers is adopted for a new board. Through a hole of each switch has been firmly soldered.
With this, it can release any excess load or vibration that you make when you type in to a board not only to a metal plate inside. It enables you to enjoy a better typing feel!

[Not only a typing feel…. but also a software got all renewed!]

Now there are many keyboards that are designed for gamers are available.
However almost all of them are designed without considering the features of a mechanical switches.
Hence, it results in experiencing unexpected troubles or errors when in use.
That may effect on the reputation of a mechanical switches.
Our new software is designed for gamers who want a premium keyboard that meets a professional usage.
We made it enable by bringing up a level of data transmission rate to maximum.
With this keyboard, you don't need any other pretentious keyboards!

[A true N-key rollover]

It is the functionality by which all the typed keys are recognized on the PC, even when many keys are typed simultaneously.
All the keys typed simultaneously are recognized on the PS/2. (Limited to 6 keys typed simultaneously for the USB due to the specifications of USB.)
A completely dedicated electronic circuitry to this model !
On our models a diode is soldered on the printed circuit for every key switch to prevent from counter currency.

[Compatibility with USB and PS/2]

A USB cable is connected to the keyboard. Plug&Play is available on each Windows system.
A PS/2 interface is also available to use the PS/2 Conversion Adapter included in the package

87 US ASCII key arrangement

Specifications

FKBN87M/EWG2
FKBN87ML/EWG2
FKBN87MC/EWG2
FKBN87MRL/EWG2
Number of keys 87 keys/US ASCII key arrangement
Key switch FKBN87M/EWG2 : Cherry MX Brown Switch (tactile feel)
FKBN87ML/EWG2 : Cherry MX Black Switch (linear)
FKBN87MC/EWG2 : Cherry MX Blue Switch (click tactile)
FKBN87MRL/EWG2 : Cherry MX Red Switch (linear)
Key pitch/Key stroke 19mm/4 ±0.5mm
Dimensions/Weight W356xD135xH33mm(44mm raised up by stand)/980g
Interface PS/2,USB (PS/2 interface is available with PS/2 Conversion Adapter)
Cable length 1.5m
Notices All our FILCO Keyboard have already passed the CE, FCC and RoHS certification.
Windows 7 Logo Program
FKBN87M/EWG2
FKBN87ML/EWG2
FKBN87MC/EWG2
FKBN87MRL/EWG2
Number of keys 87 keys/US ASCII key arrangement
Key switch FKBN87M/EWG2 : Cherry MX Brown Switch (tactile feel)
FKBN87ML/EWG2 : Cherry MX Black Switch (linear)
FKBN87MC/EWG2 : Cherry MX Blue Switch (click tactile)
FKBN87MRL/EWG2 : Cherry MX Red Switch (linear)
Key pitch/Key stroke 19mm/4 ±0.5mm
Dimensions/Weight W356xD135xH33mm(44mm raised up by stand)/980g
Interface PS/2,USB (PS/2 interface is available with PS/2 Conversion Adapter)
Cable length 1.5m
Notices All our FILCO Keyboard have already passed the CE, FCC and RoHS certification.

Windows 7 Logo Program
